2FG14 Parallel Gripper
High-force IP67 parallel gripper for heavy CNC workpieces, up to 20 kg payload.
The 2FG14 delivers high gripping power in a compact, fully electric package, handling workpieces up to 20 kg in form fit. A reinforced finger platform accepts a wide range of custom fingers, and IP67 protection lets it run reliably in machining workshops with coolant and chips in the air. Full gripping control makes deployment and redeployment fast compared with pneumatic alternatives.
Key Features
- Payload up to 20 kg in form fit, 14 kg in force fit
- 50 mm total stroke with 105 mm external grip range
- Reinforced finger platform for extensive customisation
- IP67 rated for coolant and chip exposure
- Integrated force sensor in the connector-side finger
Specifications
| Payload (force fit) | 14 kg |
| Payload (form fit) | 20 kg |
| Total stroke | 50 mm |
| Grip width range (external) | 5–105 mm |
| Grip width range (internal) | 17.6–117.6 mm |
| Gripping force | 40–280 N (±10 N) |
| Gripping speed | 16–450 mm/s |
| Gripping time | 200 ms typical |
| Gripping repeatability | ±0.1 mm |
| Allowed finger torque | 30 Nm (X), 25 Nm (Y) |
| Motor | Integrated electric BLDC |
| IP classification | IP67 |
| Dimensions | 155.2 × 115 × 70 mm |
| Weight | 1.5 kg |
| Operating temperature | 0–50 °C |
Applications
CNC machine tending
Material handling
Assembly
Heavy part transfer
