3FG25 Three-Finger Gripper
Heavy-duty centric three-finger gripper for workpieces up to 25 kg and 450 N gripping force.
The 3FG25 scales the three-finger concept up for high-payload collaborative work: 25 kg in form fit, 155 mm external grip diameter and up to 450 N of gripping force. Automatic centring gives a strong, stable grip and precise placement in machine chucks, and IP67 protection keeps it reliable in machining workshops with fluids and chips.
Key Features
- Payload up to 25 kg in form fit
- External grip diameter 18–155 mm, internal 41–184 mm
- Gripping force up to 450 N
- Accurate centric positioning from three contact points
- Fingers mountable in three positions
Specifications
| Payload (force fit, grip) | 15 kg |
| Payload (force fit, flexible grip) | 10 kg |
| Payload (form fit) | 25 kg |
| Grip diameter (external) | 18–155 mm |
| Grip diameter (internal) | 41–184 mm |
| Gripping force (grip) | 50–450 N |
| Gripping force (flexible grip) | 50–300 N |
| Gripping speed | Up to 90 mm/s |
| Gripping time | 500 ms typical |
| Diameter repetition accuracy | 0.1 mm typical |
| Motor torque on finger platform | 7.4 Nm |
| IP classification | IP67 |
| Dimensions | 156 × 168 × Ø187 mm |
| Weight | 1.6 kg |
| Operating temperature | 5–50 °C |
Applications
CNC machine tending
Material handling
Assembly
Transferring
Sorting
