Dual Mounting Kit
Mounts two independent Quick Changers in any orientation your application needs.
Where the Dual Quick Changer fixes two tools in one housing, the Dual Mounting Kit uses two independent Quick Changers that can be positioned and oriented freely. That extra freedom helps when the two tools need different approach angles, and the kit also improves cable routing for cleaner installations and faster integration.
Key Features
- Two independent Quick Changers, freely positioned and oriented
- Greater tool-placement flexibility than the Dual Quick Changer
- Improved cable management for cleaner installations
- Combined payload up to 25 kg
- ±0.02 mm repeatability
Specifications
| Rated payload | 25 kg |
| Permissible force | 400 N |
| Permissible torque | 40 Nm |
| Repeatability | ±0.02 mm |
| IP classification | IP67 |
| Operating life (tool change) | 5,000 cycles |
| Weight (per Quick Changer) | 0.06 kg |
| Flange standard | ISO 9409-1 |
| Operating temperature | 0–50 °C |
| Components | Quick Changer A (114975), B (114972), splitter (114999) |
Applications
CNC machine tending
Material handling
Assembly
Material removal
Quality inspection
